Signage Solutions Multi-Touch Display
10BDL4551T/00
Big impact
From shelf advertising to wayfinding, this ultra-clear Multi-Touch Smart Display is ideal when space is at a premium. A versatile all-in-one solution, content is easy to manage remotely. Power-over-Ethernet enables flexible placement
Unfortunately this product is no longer available
This product qualifies for VAT relief
If you're eligible for VAT relief on medical devices, you can claim it on this product. The VAT amount will be deducted from the price shown above. Look for full details in your shopping basket.
Signage Solutions Multi-Touch Display
Similar products
See all Unmapped
CMND & Create. Develop and launch your own content
Take control of your content with CMND & Create. A drag-and-drop interface makes it simple to publish your own content-whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure your stills, text, and video will be up and running in no time.
Operate, monitor and maintain with CMND & Control
Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.
Built-in camera and speakers
The built-in camera and speakers make this small touchscreen a truly versatile smart solution. Use it for retail audience measurement, footfall analytics, and more. Harness the power of Android AI apps to show targeted content. Or simply use your display for video conferencing.
Easy installation with PoE+ technology
Place your Philips Professional Display almost anywhere. PoE+ allows power and data to be delivered to your display over a single Ethernet cable. You won't need a power socket, but a power adapter is also supplied should you wish to plug in.
Internal memory. Upload content for instant play
Save and play content without the need for a permanent external player. Your Philips professional display has an internal memory, which allows you to upload media into the display for instant playback. The internal memory also functions as a cache for online streaming.
CMND & Deploy. Install and launch apps remotely
Quickly install and launch any app-even when you're off-site and working remotely. CMND & Deploy lets you add and update your own apps, as well as apps from the Philips Professional Display App Store. Simply scan the QR code, log in to the store, and click on the app you want to install. The app is automatically downloaded and launched.
Android SoC processor. Native and web apps
Control your display via an Internet connection. Android-powered Philips Professional Displays are optimized for native Android apps, and you can install web apps directly to the display too. A new Android 8 ensures the software is kept secure and remain to the latest specification for longer.
Technical Specifications
-
Connectivity
- Audio output
- External speaker connector
- Other connections
-
- USB
- micro SD
-
- Video output
- HDMI
- External control
- RJ45
-
Picture/Display
- Diagonal screen size (metric)
- 25.6 cm
- Diagonal screen size (inch)
- 10.1'' inch
- Aspect ratio
- 16:10
- Panel resolution
- 1280 x 800
- Optimum resolution
- 1280 x 800
- Brightness
- 300 cd/m²
- Display colors
- 16.7 million
- Contrast ratio (typical)
- 800:1
- Response time (typical)
- 30 ms
- Viewing angle (horizontal)
- 160 degree
- Viewing angle (vertical)
- 160 degree
- Operating system
- Android 8.1
-
Convenience
- Placement
-
- Landscape (24/7)
- Portrait (24/7)
-
- Screen saving functions
- Low Brightness
- Keyboard control
-
- Hidden
- Lockable
-
- Energy saving functions
- Smart Power
- Picture performance
- Advanced color control
- Network controllable
-
- RJ45
- WiFi
-
- Memory
- 2GB DDR3/ 8GB eMMC
-
Sound
- Built-in speakers
- 2 x 2W
-
Power
- Mains power
- DC12V +/- 5%, 1.5A, PoE=24W
- Consumption (Max)
- 10.96 W
- Standby power consumption
- <0.5W
-
Dimensions
- Set Width
- 261 mm
- Product weight
- 0.74 kg
- Set Height
- 167.2 mm
- Set Depth
- 29 mm
- Set Width (inch)
- 10.28 inch
- Set Height (inch)
- 6.58 inch
- Wall Mount
- 75 x 75
- Set Depth (inch)
- 1.14 inch
- Bezel width (L/R, T/B)
- 19.77 (L/R), 13.56 (T/B) mm
- Product weight (lb)
- 1.63 lb
-
Operating conditions
- Altitude
- 0 ~ 3000 m
- Temperature range (operation)
- 0 ~ 40 °C
- MTBF
- 50,000 hour(s)
- Relative humidity
- 10 ~ 85(non-condensing) %
- Temperature range (storage)
- -20 ~ 60 °C
-
Multimedia Applications
- USB Playback Video
-
- MOV
- MP4
- MPG
- TS
- VOB
- WEBM
- 3GP
- AVI
- DAT
- FLV
- MKV
-
- USB Playback Picture
-
- BMP
- GIF
- JPEG
- PNG
-
- USB Playback Audio
-
- AAC
- M4A
- MP2
- MP3
- WMA
-
-
Accessories
- Included accessories
-
- Quick start guide
- Table top stand
- USB cable
- DC power adapter
- HDMI cable
- Power plug
- Silicon foot
-
-
Miscellaneous
- On-Screen Display Languages
-
- Arabic
- English
- French
- German
- Italian
- Japanese
- Polish
- Spanish
- Turkish
- Russian
- Simplified Chinese
- Traditional Chinese
- Danish
- Dutch
- Finnish
- Norwegian
- Portuguese
- Swedish
-
- Warranty
- 3 year warranty
- Regulatory approvals
-
- CB
- CE
- RoHS
- FCC, Class A
- UL
-
-
Interactivity
- Multi-touch technology
- Projected capacitive
- Touch points
- 5 simultaneous touchpoints
- Protection glass
- 0.7 mm tempered safety glass
